| Locator | NW Mech Dwg - NW-D26937 | Type | Drawing | Doc Number | D26937 | |
|---|---|---|---|---|---|---|
| Description | Arrangement and Detail of Mllet Hinge Loco Class Y4 | |||||
| Date | 09/27/1926 | Revision Date | 09/18/1933 | |||
| Author | N&W Rwy - Motive Power | Accession | 2001.001 : Mark Faville | |||
|
||
Size: 32in x 22in (83cm x 57cm) |
| Rolling Stock Indexes | |||||
|---|---|---|---|---|---|
| Category | Type | Road Name | Class | Builder | Other |
| Locomotive | Steam | N&W Rwy | Y4 | Alco-Richmond | 2-8-8-2 |
