Locator NW Mech Dwg - NW-J35892 Type Drawing Doc Number J35892
Description Cylinder, (Right Half), H.P. Loco. Class Y3, Y3a, Y4 (Style No. 1 - Cast Steel)
Date 11/04/1938 Revision Date 11/03/1955
Author N&W Rwy - Motive Power Accession 2001.001 : Mark Faville

Cylinder, (Right Half), H.P. Loco. Class Y3, Y3a, Y4 (Style No. 1 - Cast Steel)

Size: 7.13ft x 38in (2.2m x 96cm)

Rolling Stock Indexes
Category Type Road Name Class Builder Other
Locomotive Steam N&W Rwy Y3   2-8-8-2
Locomotive Steam N&W Rwy Y3a   2-8-8-2
Locomotive Steam N&W Rwy Y4 Alco-Richmond 2-8-8-2
