| Locator | Hist Soc - HS-D10241 | Type | Drawing | Doc Number | E-148 | |
|---|---|---|---|---|---|---|
| Description | Standard 16'-6" Split Switch Using Adjustable Rail Braces 131 & 132 Lb RE Rails (switch machine) (hand throw) | |||||
| Notes | Sheet 1 of 2 | |||||
| Date | 11/17/1947 | Revision Date | 11/01/1954 | |||
| Author | VGN Railway | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 30in x 17in (77cm x 44cm) |
| Related | E-148 | Hist Soc - HS-D10258 | Standard 16'-6" Split Switch Using Adjustable Rail Braces 131 & 132 Lb RE Rails Sheet 2 of 2 |
| Structure | Track - Switch |
| Structure | Track - Rail |
