| Locator | NW Mech Dwg - NW-D22430 | Type | Drawing | Doc Number | D22430 | |
|---|---|---|---|---|---|---|
| Description | Arrangement & Details of Coal Gate for 15000, 16000, 18000 Gallon Tender Tank for Loco Class Y2a, Y3, K2a, Y3a, K3, Y3b, with Duplex Stoker | |||||
| Date | 05/16/1922 | Revision Date | 06/29/1927 | |||
| Author | N&W Rwy - Motive Power | Accession | 2001.001 : Mark Faville | |||
|
||
Size: 34in x 24in (87cm x 62cm) |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Baldwin - K2a - 4-8-2 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Roanoke Shops - K3 - 4-8-2 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Y2a - 2-8-8-2 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Y3 - 2-8-8-2 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Y3a - 2-8-8-2 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Y3b - 2-8-8-2 |
| Rolling Stock | N&W Rwy - Tender - Locomotive - 16,000 gal. |
| Rolling Stock | N&W Rwy - Tender - Locomotive - 18,000 gal. |
| Rolling Stock | N&W Rwy - Tender - Locomotive - 15,000 gal. |
