Locator NW Mech Dwg - NW-E26974 Type Drawing Doc Number E26974
Description Cylinder, Loco. Class Y3, Y3a, Y4 (Y5 Without Roller Bearings.) (H. P. Right)
Date 10/04/1926 Revision Date 10/26/1942
Author N&W Rwy - Motive Power Accession 2001.001 : Mark Faville

Cylinder, Loco. Class Y3, Y3a, Y4 (Y5 Without Roller Bearings.) (H. P. Right)

Size: 38in x 30in (97cm x 77cm)

Rolling Stock N&W Rwy - Locomotive - Steam - Y3 - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Y3a - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Alco-Richmond - Y4 - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Roanoke Shops - Y5 - 2-8-8-2
