| Locator | Hist Soc - HS-K00186 | Type | Drawing | Doc Number | B-3921 2829 | |
|---|---|---|---|---|---|---|
| Description | VGN, Station Layout at Fagg | |||||
| Notes | Scale 1"=100', MP 277.5, Shows wye at 277, Water tank east of station (near end of passing siding) | |||||
| Date | 06/24/1907 | Revision Date | ||||
| Author | VGN Rwy - Office Chief Engr | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 54in x 17in (138cm x 44cm) |
| Cities Indexes | |
|---|---|
| City | State |
| Fagg | VA |
| Structures Indexes | |
|---|---|
| Category | Type |
| Engine Service | Water |
| Track | Wye |
| Station | |
| Tank | Water |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| VGN Rwy | Virginian Railway |
| Division Indexes | |||
|---|---|---|---|
| Road Name | Division | District/Branch | Mile Post |
| VGN Rwy | New River | 277 | |
