Locator NW Mech Dwg - NW-F28667 Type Drawing Doc Number F28667
Description Parallel Rods with Floating Bushings, Locos Class Y3, Y3a, Y4, Y5 (Style No. 2F)
Date 04/09/1928 Revision Date 01/17/1945
Author N&W Rwy - Motive Power Accession 2018.014 : William Lee Manes

Parallel Rods with Floating Bushings, Locos Class Y3, Y3a, Y4, Y5 (Style No. 2F)

Size: 55in x 17in (138cm x 42cm)

Rolling Stock N&W Rwy - Locomotive - Steam - Y3 - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Y3a - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Alco-Richmond - Y4 - 2-8-8-2
Rolling Stock N&W Rwy - Locomotive - Steam - Roanoke Shops - Y5 - 2-8-8-2
