| Locator | Hist Soc - HS-D10258 | Type | Drawing | Doc Number | E-148 | |
|---|---|---|---|---|---|---|
| Description | Standard 16'-6" Split Switch Using Adjustable Rail Braces 131 & 132 Lb RE Rails | |||||
| Notes | Sheet 2 of 2 | |||||
| Date | 01/16/1950 | Revision Date | 03/25/1955 | |||
| Author | VGN Railway | Accession | 2009.001 : NS Corp/Va Tech Collection | |||
|
||
Size: 30in x 18in (77cm x 45cm) |
| Structures Indexes | |
|---|---|
| Category | Type |
| Track | Switch |
| Track | Rail |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| VGN Rwy | Virginian Railway |
| Related Documents | |||
|---|---|---|---|
| Type | Number | Locator | Description |
| Related | E-148 | Hist Soc - HS-D10241 | Standard 16'-6" Split Switch Using Adjustable Rail Braces 131 & 132 Lb RE Rails (switch machine) (hand throw) |
| Related | Library - | Virginian Railway Feature, Historical and Biographical, Sam R. Pennington's Feature Stories Magazine, June 1933, Vol 2. No. 1 | |
