Locator NW Mech Dwg - NW-F28667 Type Drawing Doc Number F28667
Description Parallel Rods with Floating Bushings, Locos Class Y3, Y3a, Y4, Y5 (Style No. 2F)
Date 04/09/1928 Revision Date 10/15/1952
Author N&W Rwy - Motive Power Accession 2001.001 : Mark Faville

Parallel Rods with Floating Bushings, Locos Class Y3, Y3a, Y4, Y5 (Style No. 2F)

Size: 55in x 16in (140cm x 41cm)

Rolling Stock Indexes
Category Type Road Name Class Builder Other
Locomotive Steam N&W Rwy Y3   2-8-8-2
Locomotive Steam N&W Rwy Y3a   2-8-8-2
Locomotive Steam N&W Rwy Y4 Alco-Richmond 2-8-8-2
Locomotive Steam N&W Rwy Y5 Roanoke Shops 2-8-8-2
