| Locator | NW Mech Dwg - NW-E30577 | Type | Drawing | Doc Number | E30577 | |
|---|---|---|---|---|---|---|
| Description | Smoke Box and Bradford Type A Front End Throttle Valve Arrangement Loco Class Y5 | |||||
| Date | 03/06/1930 | Revision Date | 02/08/1954 | |||
| Author | N&W Rwy - Motive Power | Accession | 2001.001 : Mark Faville | |||
|
||
Size: 39in x 31in (100cm x 80cm) |
| Rolling Stock Indexes | |||||
|---|---|---|---|---|---|
| Category | Type | Road Name | Class | Builder | Other |
| Locomotive | Steam | N&W Rwy | Y5 | Roanoke Shops | 2-8-8-2 |
