| Locator | NW Mech Dwg - NW-J35891 | Type | Drawing | Doc Number | J35891 | |
|---|---|---|---|---|---|---|
| Description | Cylinder(Left Half), H.P. Loco., Class Y3, Y3a, Y4 (Style No. 1 - Cast Steel) | |||||
| Date | 10/11/1938 | Revision Date | 11/03/1955 | |||
| Author | N&W Rwy - Motive Power | Accession | 2001.001 : Mark Faville | |||
|
||
Size: 7.15ft x 38in (2.2m x 96cm) |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Y3 - 2-8-8-2 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Y3a - 2-8-8-2 |
| Rolling Stock | N&W Rwy - Locomotive - Steam - Alco-Richmond - Y4 - 2-8-8-2 |
