Locator NW Mech Dwg - NW-E39022 Type Drawing Doc Number E39022
Description Cross Sections, Loco. Class J (Eng. Nos. 605-613) Sheet No. 1.
Date 03/23/1943 Revision Date 06/07/1951
Author N&W Rwy - Motive Power Accession

Cross Sections, Loco. Class J (Eng. Nos. 605-613)  Sheet No. 1.

Size: 38in x 31in (97cm x 78cm)

Rolling Stock Indexes
Category Type Road Name Class Builder Other
Locomotive Steam N&W Rwy J Roanoke Shops 4-8-4
