| Locator | NW Mech Dwg - NW-D30346 | Type | Drawing | Doc Number | D30346 | |
|---|---|---|---|---|---|---|
| Description | Bottom Draw Fulcrum, Loco. Class Y3, Y3a, Y4 | |||||
| Date | 12/10/1929 | Revision Date | 01/06/1940 | |||
| Author | N&W Rwy - Motive Power | Accession | 2001.001 : Mark Faville | |||
|
|||||
Size: 33in x 22in (83cm x 55cm) | |||||
| Rolling Stock Indexes | |||||
|---|---|---|---|---|---|
| Category | Type | Road Name | Class | Builder | Other |
| Locomotive | Steam | N&W Rwy | Y3 | 2-8-8-2 | |
| Locomotive | Steam | N&W Rwy | Y3a | 2-8-8-2 | |
| Locomotive | Steam | N&W Rwy | Y4 | Alco-Richmond | 2-8-8-2 |
| Railroads and Companies | |
|---|---|
| Abbreviation | Name |
| N&W Rwy | Norfolk & Western Railway |
