Locator Hist Soc - HS-S00006 Type Drawing Doc Number 13690-C
Description Proposed line and grade change and third track, Blake WV to Bluefield WV, MP 355.0 to MP 361.4
Notes Sheet 1. Drawing actually starts east of MP 354, and shows location of "Blake Interlocking Tower and twin 50,000 gal water tanks at Blake. Shows Mills Grave Yard at Jug Neck curve. Proposed route would have been triple track from Blake all the way to Bluefield, on south side of East River between Blake and present-day WV Route 112. Would have crossed present day WV route 112 (shown as US Route 21 on map) on a 500' +/- steel viaduct to revised original route. Obviously never built.
Date 02/16/1949 Revision Date
Author N&W Rwy - Office Chief Engr Accession 2005.004 : Library of Virginia

Proposed line and grade change and third track, Blake WV to Bluefield WV, MP 355.0 to MP 361.4

Size: 8.16ft x 11in (2.5m x 28cm)


Cities Indexes
City State
Bluefield WV
Ada WV
Blake WV

Structures Indexes
Category Type
Tower Interlocking

Division Indexes
Road Name Division District/Branch Mile Post
N&W Rwy Radford   258
